April 30, 2022MW Mean Well Meanwell 315W Constant Power Mode LED Driver XLG-320 series
Series Features
‧Wide input range 100~305V AC( Class I)
‧Full power output at 70~100% Constant power mode operation
‧Metal case with IP67, suitable for outdoor application
‧Surge protection with 6KV/4KV (10KV/6KV optional)
‧3 in 1 dimming function (Dim to off and Isolation design)
survive input voltage stress of 440Vac for 48 hours
‧Protection functions: OVP/SCP/OCP/OTP
‧Life time >50,000 hrs. and 5 years warranty
Mean Well LED Driver XLG-320 Series Data Sheet Download
Description
XLG-320 series is a 315W LED AC/DC driver featuring the constant power mode and high voltage output. XLG-320 operates from 100~305VAC and offers models with different rated current ranging between 1050mA and 18000mA. Thanks to the high efficiency up to 94.5%, with the fanless design, the entire series is able to operate for -40℃~+85℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world. XLG-320 series comply with the latest version of IEC61347/GB7000.1-2015 and UL8750 international safety regulations. The output and dimming circuit are also completely in accordance with the new regulations and isolation to ensure the safety of both user and luminaire system during installation.
In XLG family, there are XLG-20 series, XLG-25 series, XLG-50 series, XLG-75 series, XLG-100 series, XLG-150 series, XLG-200 series, XLG-240 series and XLG-320 series.
Mean Well LED Driver XLG-320 Series Model Encoding
| Type | IP Level | Function | Note |
| Blank | IP67 | Io and Vo fixed.(For harsh environment) | By request |
| A | IP67 | Output constant power adjustable via built-in Io potentiometer | In Stock |
| AB | IP67 | Output constant power adjustable via built-in Io potentiometer +
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance) |
In Stock |
Note: V model is constant voltage operation without the AB type.
Specification
| MODEL | XLG-320-L- | XLG-320-M- | XLG-320-H- | XLG-320-V- | |||
|
OUTPUT |
DEFAULT CURRENT | 1400mA | 2800mA | 5600mA | 13A/24V | ||
| RATED POWER Note.10 | 315W | 310.8W | 312W | 24V/312W, 12V/216W | |||
| CONSTANT CURRENT REGION | 150~300V | 74 ~ 148V | 30 ~ 56V | NC | |||
| OUTPUT VOLTAGE ADJ. RANGE | NC | NC | NC | 24V or 12V | |||
| FULL POWER CURRENT RANGE | 1050~1400mA | 2100~2800mA | 5570~7420mA | 13~18A(24V/13A,12V/18A) | |||
| OPEN CIRCUIT VOLTAGE (max.) | 340V | 180V | 60V | NC | |||
| CURRENT ADJ. RANGE | 500~1400mA | 1050~2800mA | 2800~7420mA | NC | |||
| CURRENT RIPPLE | 5.0% max. @rated current | 5.0 max. @rated current | 5.0% max. @rated current | NC | |||
| CURRENT TOLERANCE | ±5% | ±5% | ±5% | NC | |||
| RIPPLE & NOISE(max.) | NC | NC | NC | 240mV p-p | |||
| VOLTAGE TOLERANCE | NC | NC | NC | ±3% | |||
| LINE REGULATION | NC | NC | NC | ±0.5% | |||
| LOAD REGULATION | NC | NC | NC | ±2% | |||
| SET UP TIME Note.9 | 500ms/230VAC, 1200ms/115VAC | ||||||
| RISE TIME,HOLD UP TIME (Typ.) | 160ms,10ms/230VAC/115VAC(only for V-type) | ||||||
|
INPUT |
VOLTAGE RANGE Note.2 | 100 ~ 305VAC 142VDC ~ 431VDC
(Please refer to “STATIC CHARACTERISTIC” ang “ DRIVING METHODS OF LED MODULE”section) |
|||||
| FREQUENCY RANGE | 47 ~ 63Hz | ||||||
| POWER FACTOR (Typ.) | PF≧0.98 / 115VAC, PF≧0.95 / 230VAC, PF≧0.92 / 277VAC at full load
(Please refer to “Power Factor Characteristic” section) |
||||||
| TOTAL HARMONIC DISTORTION | THD< 10% @ load≧50% at 115VAC/230VAC, THD<15%@Load>75% at 277VAC;
Please refer to “TOTAL HARMONIC DISTORTION (THD)” section |
||||||
| EFFICIENCY (Typ.) | 94.5% | 93.5% | 92.5% | 93% | |||
| AC CURRENT (Typ.) | 3A / 120VAC 1.6A / 230VAC 1.3A / 277VAC | ||||||
| INRUSH CURRENT(Typ.) | COLD START 45A(twidth=1200μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 | ||||||
| MAX. NO. of PSUs on 16A
CIRCUIT BREAKER |
2 unit(circuit breaker of type B) / 4 units(circuit breaker of type C) at 230VAC | ||||||
| LEAKAGE CURRENT | <0.75mA / 277VAC | ||||||
| STANDBY POWER CONSUMPTION Note.5 | Standby power consumption <0.5W for AB-Type(Dimming OFF) | ||||||
|
PROTECTION |
SHORT CIRCUIT | Hiccup mode or Constant current limiting, recovers automatically after fault condition is removed | |||||
| OVER VOLTAGE | 350 ~ 380V | 190 ~ 220V | 63 ~ 78V | 27 ~ 34V | |||
| Shut down output voltage, re-power on to recovery | |||||||
| OVER TEMPERATURE Note.11 | L/M/H-Type: Tcase>85℃±5℃,derate power automatically V-Type: Shut down output voltage, re-power on to recover | ||||||
| OVER LOAD | 108~135%(only for V-type) | ||||||
| Hiccup mode or Constant current limiting, recovers automatically after fault condition is removed | |||||||
|
ENVIRONMENT |
WORKING TEMP. | Tcase=-40 ~ +85℃(Please refer to “OUTPUT LOAD vs TEMPERATURE” section) | |||||
| MAX. CASE TEMP. | Tcase=+85℃ | ||||||
| WORKING HUMIDITY | 20 ~ 95% RH non-condensing | ||||||
| STORAGE TEMP., HUMIDITY | -40 ~ +80℃, 10 ~ 95% RH non-condensing | ||||||
| TEMP. COEFFICIENT | ±0.03%/℃ (0 ~ 60℃) | ||||||
| VIBRATION | 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes | ||||||
|
SAFETY & EMC |
SAFETY STANDARDS | UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384; GB19510.1, GB19510.14;EAC TP TC 004; IP67 approved | |||||
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC | ||||||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH | ||||||
|
EMC EMISSION |
Parameter | Standard | Test Level / Note | ||||
| Conducted | BS EN/EN55015(CISPR15) ,GB/T17743 | —– | |||||
| Radiated | BS EN/EN55015(CISPR15),GB/T17743 | —– | |||||
| Harmonic Current | BS EN/EN61000-3-2 , GB/T17625.1 | Class C @load≥50% | |||||
| Voltage Flicker | BS EN/EN61000-3-3 | —– | |||||
|
EMC IMMUNITY |
BS EN/EN61547 | ||||||
| Parameter | Standard | Test Level / Note | |||||
| ESD | BS EN/EN61000-4-2 | Level 3, 8KV air ; Level 2, 4KV contact | |||||
| Radiated | BS EN/EN61000-4-3 | Level 2 | |||||
| EFT / Burst | BS EN/EN61000-4-4 | Level 3 | |||||
| Surge | BS EN/EN61000-4-5 | 4KV/Line-Line 6KV/Line-Earth | |||||
| Conducted | BS EN/EN61000-4-6 | Level 2 | |||||
| Magnetic Field | BS EN/EN61000-4-8 | Level 4 | |||||
| Voltage Dips and Interruptions | BS EN/EN61000-4-11 | >95% dip 0.5 periods, 30% dip 25 periods,
>95% interruptions 250 periods |
|||||
|
OTHERS |
MTBF | 1476.4K hrs min. Telcordia SR-332(Bellcore) ; 168.1 K hrs min. MIL-HDBK-217F (25℃) | |||||
| DIMENSION | 246*77*39.5mm (L*W*H) | ||||||
| PACKING | 1.45Kg; 9pcs/14Kg/0.76CUFT | ||||||
Application
‧Bay lighting
‧Stage lighting
‧Floodlight lighting
‧Fishing lighting
‧Horticulture lighting
‧Stadium lighting
‧DMX power supply
‧Type “HL” for use in class Ⅰ, Division 2
